WR-MPC3 3 mm Micropower Connectors
Würth Elektronik's connectors are available in a variety of PCB fixations
Würth Elektronik's 3.00 mm micro power connectors are designed to meet customer requirements when high current is needed in a limited amount of space. The WR-MPC3 series is composed of three components that interact with the wires and the PCB.
The WR-MPC3 connectors offer a variety of PCB fixations including snap-in pegs, mounting flanges, solder tabs, metal clips, and single and dual rows. These connectors are available in receptacles, headers, plugs, terminals, 2 pins to 24 pins, THT, SMT, crimp types (20 AWG to 30 AWG), and straight and angled types.
- Current rating: up to 5 A
- Working voltage: up to 250 VAC
- UL certification
- RoHS compliance
- Glow wire design available
- Coded system to prevent mismatching
- Highly secure positive locking system
- Low-force terminals available
- Wire-to-board and wire-to-wire solutions
Cable Assemblies
Abbildung | Hersteller-Teilenummer | Beschreibung | Länge | Drahtstärke | Kontaktoberfläche | Verfügbare Menge | Preis | Details anzeigen | |
---|---|---|---|---|---|---|---|---|---|
![]() | ![]() | 662100124015 | WR-MPC3 3,00 MM PRE-CRIMPED CONT | 5,90" (149,86mm) | 24 AWG | Zinn | 1164 - Sofort | $0.80 | Details anzeigen |
![]() | ![]() | 662162120030 | WR-MPC3 3,00 MM PRE-CRIMPED CONT | 11,8" (300,0mm) | 20AWG | Zinn | 3162 - Sofort | $1.15 | Details anzeigen |
![]() | ![]() | 662200124015 | WR-MPC3 3,00 MM PRE-CRIMPED CONT | 5,90" (149,86mm) | 24 AWG | Zinn | 34 - Sofort | $0.81 | Details anzeigen |
![]() | ![]() | 662262220030 | WR-MPC3 3,00 MM PRE-CRIMPED CONT | 11,8" (300,0mm) | 20AWG | Zinn | 0 - Sofort | $1.19 | Details anzeigen |
![]() | ![]() | 662400130015 | CONMPC3 MICRO POWER CONNECTORS 3 | 5,90" (149,86mm) | 30 AWG | Zinn | 10 - Sofort | $0.82 | Details anzeigen |
![]() | ![]() | 662662626030 | CONMPC3 MICRO POWER CONNECTORS 3 | 11,8" (300,0mm) | 26AWG | Zinn | 0 - Sofort | $1.28 | Details anzeigen |
![]() | ![]() | 662462426030 | CONMPC3 MICRO POWER CONNECTORS 3 | 11,8" (300,0mm) | 26AWG | Zinn | 40 - Sofort | $1.28 | Details anzeigen |
![]() | ![]() | 662562526030 | CONMPC3 MICRO POWER CONNECTORS 3 | 11,8" (300,0mm) | 26AWG | Zinn | 443 - Sofort | $1.28 | Details anzeigen |
![]() | ![]() | 662500130015 | CONMPC3 MICRO POWER CONNECTORS 3 | 5,90" (149,86mm) | 30 AWG | Zinn | 10 - Sofort | $0.82 | Details anzeigen |
![]() | ![]() | 662600130015 | CONMPC3 MICRO POWER CONNECTORS 3 | 5,90" (149,86mm) | 30 AWG | Zinn | 0 - Sofort | $0.69 | Details anzeigen |
Connector Kits
Abbildung | Hersteller-Teilenummer | Beschreibung | Werte | Verfügbare Menge | Preis | Details anzeigen | ||
---|---|---|---|---|---|---|---|---|
![]() | ![]() | 662001 | MINI POWER CONNECTORS WR-MPC3 | 193 Komponenten - Sortiment aus 166 Werten | 1 - Sofort | $84.91 | Details anzeigen |
Tools
Abbildung | Hersteller-Teilenummer | Beschreibung | Verfügbare Menge | Preis | Details anzeigen | |
---|---|---|---|---|---|---|
![]() | ![]() | 600300300001 | CONTOOL CRIMP HEAD FOR CONMPC3 | 23 - Sofort | $179.96 | Details anzeigen |
![]() | ![]() | 600662403001 | CONTOOL APPLICATOR KIT FOR CONMP | 0 - Sofort | $302.37 | Details anzeigen |
![]() | ![]() | 600662401001 | CONTOOL APPLICATOR KIT FOR CONMP | 0 - Sofort | $269.28 | Details anzeigen |
![]() | 600662324200 | WR-MPC3 DIE SET FOR 600003 | 0 - Sofort | $160.83 | Details anzeigen | |
![]() | ![]() | 600662403 | TOOL PRESS APPLICATOR 20-24AWG | 0 - Sofort | $2,297.24 | Details anzeigen |
![]() | ![]() | 600662401 | TOOL PRESS APPLICATOR 20-24AWG | 0 - Sofort | $2,439.37 | Details anzeigen |
![]() | ![]() | 600662 | EXTRACTION TOOL FOR WR-MPC3 | 28 - Sofort | $34.84 | Details anzeigen |
Connectors/Interconnects
Abbildung | Hersteller-Teilenummer | Beschreibung | Verfügbare Menge | Preis | Details anzeigen | |
---|---|---|---|---|---|---|
![]() | ![]() | 66200413722DEC | CONN SOCKET 26-30AWG CRIMP TIN | 2666 - Sofort | $0.23 | Details anzeigen |
![]() | ![]() | 66200613722DEC | CONN SOCKET 26-30AWG CRIMP TIN | 497 - Sofort | $0.26 | Details anzeigen |
