Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
640457-2 | ||
|---|---|---|
Digi-Key Part Number | A1926-ND | |
Manufacturer | ||
Manufacturer Product Number | 640457-2 | |
Description | CONN HEADER R/A 2POS 2.54MM | |
Manufacturer Standard Lead Time | 19 Weeks | |
Detailed Description | Connector Header Through Hole, Right Angle 2 position 0.100" (2.54mm) | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | 640457-2 Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Active | |
Connector Type | ||
Contact Type | Male Pin | |
Pitch - Mating | ||
Number of Positions | ||
Number of Rows | 1 | |
Row Spacing - Mating | - | |
Number of Positions Loaded | All | |
Style | ||
Shrouding | Shrouded - 1 Wall | |
Mounting Type | ||
Termination | Solder | |
Fastening Type | Friction Lock | |
Contact Length - Mating | 0.295" (7.49mm) | |
Contact Length - Post | 0.140" (3.56mm) | |
Overall Contact Length | - | |
Insulation Height | 0.225" (5.72mm) | |
Contact Shape | Square | |
Contact Finish - Mating | Tin | |
Contact Finish Thickness - Mating | - | |
Contact Finish - Post | Tin | |
Contact Material | Copper Alloy | |
Insulation Material | Thermoplastic | |
Features | - | |
Operating Temperature | -55°C ~ 105°C | |
Ingress Protection | - | |
Material Flammability Rating | UL94 V-0 | |
Insulation Color | Natural | |
Current Rating (Amps) | Varies by Wire Gauge | |
Voltage Rating | 250VAC | |
Mated Stacking Heights | - | |
Contact Finish Thickness - Post | - | |
Applications | General Purpose | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | 640457 |
| Environmental Information | 640457-2 Statement of Compliance |
| Featured Product | MTA Connectors |
| PCN Design/Specification | Multiple Drawings Update 24/Jul/2014 |
| EDA Models | 640457-2 Models |
| 3D Drawings | 640457-2.pdf |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | Vendor Undefined |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
In-Stock: 20.996
Quantity
All prices are in EUR
Bulk
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | 0,17000 € | 0,17 € |
| 10 | 0,14400 € | 1,44 € |
| 100 | 0,12020 € | 12,02 € |
| 500 | 0,10544 € | 52,72 € |
| 1.000 | 0,09993 € | 99,93 € |
| 5.000 | 0,08381 € | 419,05 € |
| 10.000 | 0,07368 € | 736,80 € |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | A1926 -640457-2-SI 6404572 2266-640457-2 |
| Standard Package | 1 |
