RAPC722X
RAPC722X
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
RAPC722X
RAPC722X
RAPC722X

RAPC722X

Digi-Key Part Number
SC1313-ND
Manufacturer
Switchcraft Inc.
Manufacturer Product Number
RAPC722X
Description
CONN PWR JACK 2X5.5MM SOLDER
Manufacturer Standard Lead Time
8 Weeks
Detailed Description
Power Barrel Connector Jack 2.00mm ID (0.079"), 5.50mm OD (0.217") Through Hole, Right Angle
Customer Reference
Datasheet Datasheet
Product Attributes
Type
Description
Select All
Category
Mfr
Switchcraft Inc.
Series
-
Package
Bulk
Product Status
Active
Connector Type
Jack
Gender
Male
Industry Recognized Mating Diameter
2.00mm ID (0.079"), 5.50mm OD (0.217")
Actual Diameter
0.076" (1.93mm ID), 0.248" (6.30mm OD)
Number of Positions/Contacts
2 Conductors, 3 Contacts
Internal Switch(s)
Single Switch, Normally Closed
Mounting Type
Through Hole, Right Angle
Mounting Feature
-
Termination
Solder Eyelet(s)
Shielding
Unshielded
Features
-
Insulation Color
-
Voltage - Rated
-
Current Rating (Amps)
5 A
Mating Length/Depth
-
Ingress Protection
-
Material Flammability Rating
-
Operating Temperature
-
Contact Material - Plating
Silver
Body Material
-
Includes
-
Housing Material
Thermoplastic
Contact Material
Brass
Thread Size
-
Body Color
Black
Base Product Number
RAPC72
Documents & Media
Resource TypeLink
Environmental InformationSwitchcraft RoHS Cert
HTML DatasheetRAPC722X Drawing
EDA Models
Product Drawings
Environmental & Export Classifications
AttributeDescription
RoHS StatusROHS3 Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
REACH StatusREACH Unaffected
ECCNEAR99
HTSUS8536.69.4040
43.484 In Stock
All prices are in EUR
Bulk
QtyUnit PriceExt Price
11,93000 €1,93 €
251,11040 €27,76 €
1001,07200 €107,20 €
Manufacturers Standard Package
Mating Products
You May Also Be Interested InSee All 11
Additional Resources
AttributeDescription
Other Names
Q5396740ZZZ
RAPC722X-ND
Q2287470A
SC1313
Standard Package100
