MRF112
MRF112
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
MRF112
MRF112
MRF112

MRF112

Digi-Key Part Number
360-2370-ND
Manufacturer
NKK Switches
Manufacturer Product Number
MRF112
Description
SWITCH ROTARY 2-12POS 0.4VA 28V
Manufacturer Standard Lead Time
13 Weeks
Detailed Description
Rotary Switch 2 ~ 12 Position SP12T 0.4VA (AC/DC) 28 VAC Through Hole
Customer Reference
Datasheet Datasheet
Product Attributes
Type
Description
Select All
Category
Mfr
NKK Switches
Series
MR
Package
Box
Product Status
Active
Number of Positions
2 ~ 12
Index Stops
Adjustable
Number of Decks
1
Number of Poles per Deck
1
Circuit per Deck
SP12T
Contact Timing
Non-Shorting (BBM)
Current Rating (Amps)
0.4VA (AC/DC)
Voltage Rating - AC
28 V
Voltage Rating - DC
28 V
Actuator Type
Screwdriver Slot
Actuator Length
Flush
Angle of Throw
30°
Contact Material
Phosphor Bronze
Contact Finish
Gold
Mounting Type
Through Hole
Termination Style
PC Pin
Features
Process Sealed
Depth Behind Panel
-
Panel Cutout Dimensions
-
Base Product Number
-
Documents & Media
Resource TypeLink
DatasheetsMR Series Half-Inch Sealed Rotaries
Product Training Modules
Video File
IP Rated Switches | Datasheet Preview
Environmental Information
CAD ModelsMRF112
PCN Design/SpecificationMRA/MRF/MRK 08/Dec/2017
EDA ModelsMRF112 by SnapEDA
Product DrawingsMRF Series
Environmental & Export Classifications
AttributeDescription
RoHS StatusROHS3 Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
REACH StatusREACH Unaffected
ECCNEAR99
HTSUS8536.50.9020
California Prop 65
Warning Information
361 In Stock
All prices are in EUR
Box
QtyUnit PriceExt Price
113,41000 €13,41 €
511,53400 €57,67 €
1010,78500 €107,85 €
259,89080 €247,27 €
509,22760 €461,38 €
1008,65100 €865,10 €
2507,95888 €1.989,72 €
5007,49750 €3.748,75 €
Manufacturers Standard Package
You May Also Be Interested InSee All 7
Additional Resources
AttributeDescription
Other Names
MR-F113
MRF112-RO
MRF112-RO-ND
360-2370
Standard Package1
