Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
0501020.WR | ||
|---|---|---|
Digi-Key Part Number | F2920TR-ND - Tape & Reel (TR) F2920CT-ND - Cut Tape (CT) F2920DKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | 0501020.WR | |
Description | FUSE BOARD MOUNT 20A 32VDC 1206 | |
Manufacturer Standard Lead Time | 13 Weeks | |
Detailed Description | 20 A AC 32 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 1206 (3216 Metric) | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | 0501020.WR Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Mounting Type | Surface Mount | |
Fuse Type | Board Mount (Cartridge Style Excluded) | |
Current Rating (Amps) | ||
Voltage Rating - DC | 32 V | |
Response Time | Fast Blow | |
Package / Case | ||
Breaking Capacity @ Rated Voltage | 150A | |
Melting I²t | 54.76 | |
Approval Agency | CSA, UL | |
Operating Temperature | -55°C ~ 150°C | |
Color | - | |
Size / Dimension | 0.126" L x 0.064" W x 0.033" H (3.20mm x 1.63mm x 0.84mm) | |
DC Cold Resistance | 0.002 Ohms |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | 501 Series Datasheet |
| Product Training Modules | Fuseology - Introduction to Fuses |
| Environmental Information | RoHS 3 Cert 0501020.WR |
| Featured Product | 501 Series |
| HTML Datasheet | 501 Series Datasheet |
| EDA Models | 0501020.WR Models |
| Product Drawings | 0501 Series |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8536.10.0040 |
| California Prop 65 |  Warning Information |
In-Stock: 32.606
Quantity
All prices are in EUR
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | 0,96000 € | 0,96 € |
| 5 | 0,93000 € | 4,65 € |
| 10 | 0,87100 € | 8,71 € |
| 50 | 0,72000 € | 36,00 € |
| 100 | 0,60020 € | 60,02 € |
| 250 | 0,58512 € | 146,28 € |
| 500 | 0,49508 € | 247,54 € |
| 1.000 | 0,43508 € | 435,08 € |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 3.000 | 0,43556 € | 1.306,68 € |
| 6.000 | 0,41943 € | 2.516,58 € |
| 15.000 | 0,40330 € | 6.049,50 € |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 0501020WR 501020 F2920DKR F2920TR F2920CT |
| Standard Package | 3.000 |
