Digi-Key Part Number
609-3694-2-ND - Tape & Reel (TR)
609-3694-1-ND - Cut Tape (CT)
609-3694-6-ND - Digi-Reel®
Manufacturer
Amphenol ICC (FCI)
Manufacturer Product Number
20021121-00008C4LF
Description
CONN HEADER SMD 8POS 1.27MM
Manufacturer Standard Lead Time
7 Weeks
Detailed Description
Connector Header Surface Mount 8 position 0.050" (1.27mm)
Customer Reference
Datasheet Datasheet
Product Attributes
Type
Description
Select All
Category
Mfr
Amphenol ICC (FCI)
Series
Minitek127® 1.27mm
Package
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Product Status
Active
Connector Type
Header
Contact Type
Male Pin
Pitch - Mating
0.050" (1.27mm)
Number of Positions
8
Number of Rows
2
Row Spacing - Mating
0.050" (1.27mm)
Number of Positions Loaded
All
Style
Board to Board
Shrouding
Unshrouded
Mounting Type
Surface Mount
Termination
Solder
Fastening Type
Push-Pull
Contact Length - Mating
0.120" (3.05mm)
Contact Length - Post
-
Overall Contact Length
-
Insulation Height
-
Contact Shape
Square
Contact Finish - Mating
Gold
Contact Finish Thickness - Mating
10.0µin (0.25µm)
Contact Finish - Post
Tin
Contact Material
Copper Alloy
Insulation Material
Thermoplastic
Features
Pick and Place
Operating Temperature
-55°C ~ 125°C
Ingress Protection
-
Material Flammability Rating
UL94 V-0
Insulation Color
Black
Current Rating (Amps)
1A per Contact
Voltage Rating
125VAC
Mated Stacking Heights
-
Contact Finish Thickness - Post
50.0µin (1.27µm)
Applications
-
Base Product Number
20021121
Documents & Media
Resource TypeLink
DatasheetsMinitek 127 Catalog
Product Training ModulesMinitek 127 Connector System
Featured Product
CAD Models
PCN Design/Specification
HTML DatasheetMinitek 127 Catalog
EDA Models
Product Drawings
Environmental & Export Classifications
AttributeDescription
RoHS StatusRoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
REACH StatusREACH Affected
ECCNEAR99
HTSUS8536.69.4040
20.397 In Stock
All prices are in EUR
Cut Tape (CT) & Digi-Reel®
QtyUnit PriceExt Price
10,75000 €0,75 €
100,63600 €6,36 €
1000,57160 €57,16 €
* All Digi-Reel orders will add a 5,50 € reeling fee.
Tape & Reel (TR)
QtyUnit PriceExt Price
6000,46765 €280,59 €
1.2000,41569 €498,83 €
1.8000,38971 €701,48 €
3.0000,37672 €1.130,16 €
6.0000,36373 €2.182,38 €
15.0000,33775 €5.066,25 €
Manufacturers Standard Package
You May Also Be Interested InSee All 27
Mating Products
Additional Resources
AttributeDescription
Other Names
2266-20021121-00008C4LF
10122279-308000RLF
2002112100008C4LF
609-3694-1
609-3694-2
609-3694-6
Standard Package600
