HE2AN-DC24V | ||
---|---|---|
Digi-Key Part Number | 255-1660-ND | |
Manufacturer | ||
Manufacturer Product Number | HE2AN-DC24V | |
Description | RELAY GEN PURPOSE DPST 25A 24V | |
Manufacturer Standard Lead Time | 12 Weeks | |
Detailed Description | General Purpose Relay DPST-NO (2 Form A) 24VDC Coil Chassis Mount | |
Customer Reference | ||
Datasheet | Datasheet |
Type | Description | Select |
---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Active | |
Mounting Type | ||
Coil Voltage | ||
Contact Form | DPST-NO (2 Form A) | |
Contact Rating (Current) | 25 A | |
Switching Voltage | 277VAC, 30VDC - Max | |
Coil Current | 80 mA | |
Coil Type | Non Latching | |
Features | - | |
Termination Style | Plug In, Quick Connect - 0.250" (6.3mm) | |
Seal Rating | - | |
Coil Insulation | - | |
Must Operate Voltage | 16.8 VDC | |
Must Release Voltage | 2.4 VDC | |
Operate Time | 30 ms | |
Release Time | 10 ms | |
Operating Temperature | -50°C ~ 55°C | |
Contact Material | Silver Tin Oxide (AgSnO) | |
Relay Type | ||
Coil Resistance | 300 Ohms | |
Base Product Number |
Resource Type | Link |
---|---|
Datasheets | HE Series Datasheet |
Other Related Documents | |
Video File | How to Choose a Relay - Another Teaching Moment Relay Basics - Another Teaching Moment | DigiKey Electronics |
Featured Product | Active Components |
HTML Datasheet | HE Series Datasheet |
Product Drawings |
Attribute | Description |
---|---|
RoHS Status | RoHS Compliant |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
ECCN | EAR99 |
HTSUS | 8536.41.0050 |
Qty | Unit Price | Ext Price |
---|---|---|
1 | 14,15000 € | 14,15 € |
10 | 12,57600 € | 125,76 € |
25 | 11,94760 € | 298,69 € |
50 | 11,31880 € | 565,94 € |
100 | 10,69000 € | 1.069,00 € |
250 | 9,74676 € | 2.436,69 € |
500 | 9,11792 € | 4.558,96 € |
1.000 | 8,64630 € | 8.646,30 € |
Attribute | Description |
---|---|
Other Names | HE2ANDC24V 255-1660 |
Standard Package | 20 |
